HAN'S Multiple Machine Automation 'ALU Series'

Meet the HAN’S LASER ALU Multi Machine

The HF Series high speed fiber laser cutting machine is Han’s premier 2D laser cutting machine.

Focusing on 12kW+ laser cutting and stable thick plate cutting, it can handle up to 40kW ultra-high power cutting.

It has a complete cutting database expertly produced over decades of R&D and includes zero 4 Han’s HF Series Han’s HF Series 5 second perforation, fast and stable thick plate piercing, low pressure cutting, mirror edge finishing and other advanced technologies, not available to common laser companies which are purely assembly focused.

Benefits

HIGH ACCELERATION

The Laser Cutting machine can reach true 2.8G acceleration and 200m/min speeds over an entire nested sheet without sacrificing accuracy and machine durability.

ULTRA-DURABLE FRAME

The hollow integrated frame is annealed and properly protected for high power usage; allowing up to 60kW without deformation.

EXTENSIVE CUTTING PARAMETERS

Every machine up to 60kW comes with Han’s expertly crafted precision cutting database; which realises the highest speed with best possible edge finish.

HAN’S 901 CNC SYSTEM

This system includes the world´s leading CNC developed by Han’s with Bosch-Rexroth while using Bosch-Rexroth servos to ensure the highest transmission performance possible. Combine this with almost 20 years at the forefront of laser cutting technology; Han’s have created the most efficient and professional solution for laser processing.

Specifications

	3015HF	4020HF	6025HF	8025HF	10025HF	10025HF	12030HF	UNITS
Machine Length	9615	11230	15700	19200	24100	28400	28400	mm
Machine Width	3040	3470	4060	4060	4230	4230	4800	mm
Machine Height	2330	2320	2400	2400	2610	2610	2610	mm
Nominal Sheet Size (X)	3000	4000	6000	8000	10000	12000	12000	mm
Nominal Sheet Size (Y)	1500	2000	2500	2500	2500	2500	3000	mm
X Axis Stroke	3050	4030	6030	8100	10100	12100	12100	mm
Y Axis Stroke	1530	2020	2520	2520	2600	2600	3080	mm
Z Axis Stroke	120	120	400	400	400	400	400	mm
X/Y Positioning Accuracy	±0.03	±0.03	±0.03	±0.03	±0.05	±0.05	±0.05	mm/m
X/Y Repositioning Accuracy	±0.02	±0.02	±0.02	±0.02	±0.05	±0.05	±0.05	mm
Max. Travelling Speed	200	200	160	160	160	160	160	m/min
Max. Accelerating Speed	2.8	2.8	2.5	2.5	2.5	2.5	2.5	G
Max. Workbench Weight	1800	3200	14400	19200	24000	28800	34400	kg
Machine Weight (Approx.)	10000	14000	20000	24000	29000	32000	34000	kg
