Pressbrake – Yawei PBH220-4100 CNC5 Synchro Pressbrake

  • PBHS220-4100 CNC5

Yawei Synchro Pressbrake, PBH220-4100 CNC5

**AVAILABLE EX STOCK**

Features include:

– 220 ton bending force
– 4100mm bending length
– 3600mm between frames
– 410mm throat depth
– 265mm ram stroke
– 530mm open height
– Hoerbiger hydraulic system (Germany)
– Delem DA-52 CNC Control
– 5 axis (Y1, Y2, X, R & CNC hydraulic crowning compensation)
– deformation compensation on throat
– full top Eurostyle tooling in 835mm lengths
– one piece full bottom multi-V block
– SMD fast wedge clamps
– 2 front sheet supports moving freely on linear guide
– 4 backgauge fingers moving freely on linear rail
– LN Tech Light Curtain
– Physical side and rear guards

Yawei PBHS series Pressbrakes maintain perfect control of the beam positioning at all times. This is achieved by fully closed loop electro-hydraulic servo control of Y1 & Y2. The beam position (Y1 & Y2) is measured by independant linear scales, attached to decoupled measuring frames.

The PBHS series are of the highest quality and are perfectly suited to high production, high accuracy work environments.

Specifications

Yawei
PBH220-4100
New
Bending - CNC Press brake, Bending - Press brake, Sheetmetal
